ambitious-aqua•3y ago

Need help with nwfilter part of libvirt VM package

I'm really bad at subnetting i think i overwrote 255.255.0.0 with 255.255.255.0, i'm a bit confused I like to block all Local network acces except for the minimum for the VM to reach the internet allowing 192.168.122.1(Gateway?) and 192.168.122.255(Broadcast?) wasnt enough? https://paste.simplylinux.ch/view/a0f14e76#Ys8nwq1NIWWXHrWOHp5UbtmaGoA6UPGz

36 Replies

Cyber Forum•3y ago

Post created!

🔎 This post has been indexed in our web forum and will be seen by search engines so other users can find it outside Discord 🕵️ Your user profile is private by default and won't be visible to users outside Discord, if you want to be visible in the web forum you can add the "Public Profile" role in <id:customize> ✅ You can mark a message as the answer for your post with Right click -> Apps -> Mark Solution (if you don't see the option, try refreshing Discord with Ctrl + R)

Collin B.•3y ago

Good afternoon, can I ask how are you hosting this VM?

ambitious-aquaOP•3y ago

Good day , It is hosted locally on Ubuntu 22,04 with mostly the default options using the standard dhcp 192.168.122.x I did not change the default i think it is partly bridged? The device is wireless so it cant be a full bridge? soo much informaton im really confused could you elaborate on your question?

national-gold•3y ago

First off, do you know what your cidr is?

ambitious-aquaOP•3y ago

I think it did comeup in my research but i dont fully remember wasnt that when you steal as many bits as you can from the host bits? oh no that was something else i think it reverse to class D/E in the ABCDE system?

national-gold•3y ago

https://www.ipaddressguide.com/cidr

IPAddressGuide.com

CIDR to IPv4 Address Range Utility Tool | IPAddressGuide

Free IP address tool to translate IPv4 address range into CIDR (Classless Inter-Domain Routing) format and vice-versa.

ambitious-aquaOP•3y ago

maybe im confusing stuff oh yes i know that every ocated adds 8 to the slash

national-gold•3y ago

You sure?

ambitious-aquaOP•3y ago

because every part has 8 bits well i think you are implying i use the mask wrong i have that feeling too but not completely sure how to go abou it

national-gold•3y ago

So you blocked all access? Even the gateway and broadcast?

ambitious-aquaOP•3y ago

yes that is what i try to undo with

  <rule action='accept' direction='inout' priority='400'>
    <ip dstipaddr='192.168.122.0' dstipmask='24'/>
  </rule>

  <rule action='accept' direction='inout' priority='400'>
    <ip dstipaddr='192.168.122.0' dstipmask='24'/>
  </rule>

` It allows everything in the 192.168.122.x (0-255) It works but i would like to narrow it down further dstipaddr='192.168.122.0' dstipmask='24 means 192.168.122.0 255.255.255.0 if i understand the documentation while dstipmask='16' means 255.255.0.0

national-gold•3y ago

Yes, that is correct

ambitious-aquaOP•3y ago

What are the mimum ips that should be allowed?

national-gold•3y ago

What are you trying to do?

ambitious-aquaOP•3y ago

i want the VM to reach the internet freely but no acces to any local netoworks

national-gold•3y ago

Let a static IP with a cidr of 32

ambitious-aquaOP•3y ago

there are currently 3. There is 192.168.0.1(Modem ISP) 192.168.2.1(my router) and 192.168.122.1(libvirts dhcp/switch)

national-gold•3y ago

I get what you're trying to do. But what is your use case for it since it is a home network.

ambitious-aquaOP•3y ago

i did asign it the static ip of 192.168.122.20 Online Gaming

national-gold•3y ago

Do you know that you are double NATed? Um.... why?

ambitious-aquaOP•3y ago

By my isp and my own router? or do you mean that i have the host and vm on different subnets?

national-gold•3y ago

Did you just plug your router into your modem?

ambitious-aquaOP•3y ago

Yes My current isp didnt allow bridge mode

national-gold•3y ago

What ISP do you have?

ambitious-aquaOP•3y ago

I'm from Europe lol It was the only optic fibre in my neighbourhood at the time

national-gold•3y ago

What ISP do you have?

ambitious-aquaOP•3y ago

but how does this all relate to my issue?

w33t•3y ago

Basically, you're gonna want to put your modem into a bridge or transparent mode, then have your router/firewall handle all of that. A double nat scenario adds a lot of clownery that's a pain to deal with.

ambitious-aquaOP•3y ago

unfotunatly that isnt possible

w33t•3y ago

You don't need to mess with your network or broadcast. Your best bet is to either make a vLAN and disable inter-vlan communication or just give it an ip with /32 within that range so it's not on any "network" that can receive communication It'll work with double-nat but just be aware that it may cause some weird problems with game servers

ambitious-aquaOP•3y ago

could you outline an example? im vry new to networking as you have noticed

national-gold•3y ago

https://kb.netgear.com/30186/What-is-double-NAT-and-why-is-it-bad

NETGEAR KB

What is double NAT and why is it bad?

Double NAT occurs when you connect your router to an ISP gateway or another router.

ambitious-aquaOP•3y ago

I guess i have always done double natted gaming than with a VM it will be tripple natting unless i use full bridge on the host but that only works over LAN i think changing my whole network probably is not something feasable at this time but the original question was which ips should the vm have acces to to reach the internet in the 192.168.122.x range

national-gold•3y ago

The gateway

w33t•3y ago

Like Carson said, the gateway is gonna handle all of your traffic inbound and outbound

ambitious-aquaOP•3y ago

i tried allowing just 192.168.122.1 but it didnt seem to work was my use of network mask ok? I will try some more things tommorow thank you for your time The issue was that although the network was properly filtered on the VM level the host was passing the all network packets through the gateway 192.168.122.1 by adding the folowing forward rules in iptable sudo iptables -I FORWARD -s 192.168.122.20/32 -d 192.168.0.0/16 -j DROP sudo iptables -I FORWARD -s 192.168.0.0/16 -d 192.168.122.20/32 -j DROP
